It increases efficiency by helping the engineer to make a more informed choice of antenna element, providing a good starting design tuned to the specifications of the application.
CST STUDIO SUITE is suitable for designing a wide range of antenna types, including horns, reflectors, wire antennas, printed antennas and arrays.Īntenna Magus is a software tool to help accelerate the antenna design and modelling process. These can be used to simulate antenna radiation patterns, installed performance and coupling in realistic environments. It also provides, given a beamwidth, the inner and outer radii of beam's coverage.ĬST Studio Suite® is an industry-leading EM simulation tool, with multiple solvers for suitable for a wide range of applications.
The Antenna Downtilt and Coverage Calculator (aka Antenna Tilt Angle Calculator) is used to determine the approximate downward angle, measured in degrees, which the transmitting antenna is to be positioned for optimal signal strength and coverage.
Antenna Downtilt and Coverage Calculator Pasternack
